About The Mulberry

The Mulberry pairs warm greige board-and-batten with a dark bronze roof and a cedar porch that turns the corner. The front door opens into a long great room, with the kitchen at the back and a covered porch beyond its glass door. A mudroom and laundry space connects the house to the attached garage. The primary bedroom has its own bath and walk-in closet, while a second bedroom sits across the great room.

Highlights

8-ft wraparound front and side porch
16 x 8 ft covered back porch
Attached two-car garage under one roof
Walk-in pantry beside the kitchen
Primary suite with walk-in closet

Best for: A small household that wants porch time and an attached garage.

This plan is in: 2 bedroom barndominium floor plans · Barndominium with garage floor plans · Small barndominium floor plans · Farmhouse barndominium floor plans

In the $149 plan set

Builder-ready drawing set, dimensioned to the inch
Floor plan with every room, door and window located
Four exterior elevations
Building sections and roof plan
Door and window schedules
Electrical, smoke and CO placement diagram
Foundation outline
Editable CAD file (DXF) of the floor plan for your builder or drafter
Every concept rendering of the home, full-size
License to build one home

Completed by your local team

Structural design and member sizing (beams, footings, framing)
Engineering stamps or seals
Site-specific engineering, energy or code review
Permits or permit approval

Your local builder and, where your project needs one, a licensed engineer or architect complete these for your site and local codes.

Living in The Mulberry

Who it suits

The Mulberry suits a small household that wants an attached garage and a porch along two sides of the house. The garage meets the mudroom, and the front door opens directly into the shared living space.

Room by room

Great room: the front wall has a 3 ft entry door between two 2 ft 6 in wide windows; a 5 ft glass door on the rear wall leads toward the covered porch.
Primary suite: the bedroom is 12 ft 6 in by 15 ft, with windows on the front and left walls; its bath and walk-in closet each open from the bedroom.
Bedroom 2: 11 x 12 ft, with a front window and a door from the great room. Bath 2 also opens from the great room.
Kitchen side: the walk-in pantry opens from the great room, while the mudroom and laundry space leads to the garage and the mechanical room.

Build notes

One 6:12 gable roof spans the house and right-hand garage, with an 11 ft eave and one ridge.
The wraparound porch runs 42 ft across the front and 30 ft along the left side, with an 8 ft depth on both legs.
The covered back porch is 16 x 8 ft; both porch roofs are shown at 3:12.
The plan is drawn for conventional wood framing. Your builder or engineer adapts it for steel or post-frame construction and decides structural members, footings and connections.

The exterior and interior images are concept renderings of this design, not photographs of a built home. Finishes and fixtures are illustrative; the plan governs. The floor plan is drawn from the plan set. Areas are approximate and measured to the outside face of exterior walls; porches, garages and shops are listed separately.

Floor plan and specifications

Every room is dimensioned and every door and window carries its size, straight from the plan set.

The Mulberry: main floor plan with room dimensions and door and window sizes — Main floor plan. Tap to open full size.

Overall footprint: 66 ft wide by 30 ft deep, the buildings' footprint without porches and decks
Stories: 1 story
Roof (main house): 6:12 pitch, 18 in overhangs
Eave 11'-0", ridge 18'-6"
Ridge runs left-to-right, parallel to the front wall
Masses: House: 42' x 30', living space, eave 11'-0", ridge 18'-6"
Garage: 24' x 30', eave 11'-0", ridge 18'-6"
Porches: Wraparound porch: 42' x 8' front, 30' x 8' left, 3:12 shed roof attached at 11 ft, beam 9 ft high at the posts, 12 posts
Covered back porch: 16' x 8', 3:12 shed roof attached at 11 ft, beam 9 ft high at the posts, 3 posts
Structure: Drawn for conventional wood (stick) framing; trusses, posts, beams and footings are sized by the builder's engineer. A steel-frame or post-frame version is an adaptation your builder or engineer makes. Member sizes, connections and loads are by your builder's engineer for your site.
Foundation: Typical starting point: monolithic slab-on-grade with a thickened edge (a stem wall where frost depth requires), footings below the local frost line, a footing under every interior bearing line and girder point, and porch-post footings with uplift ties. Slab thickness, footing sizes, reinforcing and anchorage are sized by your engineer for your soil, frost depth and loads; shop and garage slabs are usually heavier than living-area slabs.
Counts: 8 windows, 3 exterior doors, 2 overhead doors, 15 porch posts

Rooms

Room	Size	Area
Primary bedroom	12'-6" x 15'-0"	188 sq ft
Primary bath	7'-6" x 13'-6"	101 sq ft
Walk-in closet	4'-6" x 13'-6"	61 sq ft
Great room / kitchen / dining	16'-6" x 29'-0"	478 sq ft
Bedroom 2	11'-0" x 12'-0"	132 sq ft
Bath 2	11'-0" x 5'-0"	55 sq ft
Mudroom / laundry	11'-0" x 6'-0"	66 sq ft
Walk-in pantry	5'-0" x 4'-6"	22 sq ft
Mechanical	5'-6" x 4'-6"	25 sq ft
Garage	23'-0" x 29'-0"	667 sq ft

Doors and windows

Swipe the table sideways to see sill, room and wall.

ID	Type	Size	Sill	Room	Wall
W01	Casement window	4'-0" x 5'-0"	2'-0"	Primary bedroom	Front
W02	Window	2'-6" x 6'-0"	2'-0"	Great room / kitchen / dining	Front
W03	Window	2'-6" x 6'-0"	2'-0"	Great room / kitchen / dining	Front
W04	Casement window	4'-0" x 5'-0"	2'-0"	Bedroom 2	Front
W05	Casement window	4'-0" x 5'-0"	2'-0"	Primary bedroom	Left side
W06	Window	2'-0" x 2'-0"	5'-0"	Primary bath	Rear
W07	Window	4'-0" x 3'-6"	3'-6"	Great room / kitchen / dining	Rear
W09	Window	4'-0" x 3'-0"	4'-0"	Garage	Rear
D01	Entry door	3'-0" x 8'-0"	no sill	Great room / kitchen / dining	Front
D02	Glass slider or French door	5'-0" x 8'-0"	no sill	Great room / kitchen / dining	Rear
D03	Door	3'-0" x 6'-8"	no sill	Garage	Right side
G01	Overhead door	9'-0" x 8'-0"	no sill	Garage	Front
G02	Overhead door	9'-0" x 8'-0"	no sill	Garage	Front

Sizes are clear inside dimensions for rooms and rough openings for doors and windows, from the plan set. Roof heights are above the finished floor. The structure and foundation lines are typical starting points: the drawings are not stamped, and your builder's engineer sizes members, footings and anchorage for your site, soil, snow, wind and frost depth.
